Installation method of ice maker

1. Placement of the ice maker

(1) The machine should be placed in a safe and clean place with air circulation.

(2) The machine should not be placed in the open air, and should not be exposed to direct sunlight and rain. Keep away from heat sources.

The operating environment of the machine shall not be lower than 5 ℃ and not higher than 38 ℃.

(4) There should be sufficient space around the machine, especially at the rear, which should not be less than 150mm. So that the machine can dissipate heat.

(5) Please adjust the foundation screws at the bottom of the machine to ensure that the machine is placed horizontally and stably.

2. Installation of water system

Please connect to a water source that meets local drinking water standards.

(2) Connect a filter if necessary to improve the drinking standard of water.

(3) The water supply system must meet the following conditions:

A.The minimum water temperature is 2 ℃, and the maximum water temperature is not more than 38 ℃

B. Water pressure: minimum 0.02Mpa, maximum 0.8Mpa

3. Installation of power supply

(1) The power supply must be consistent with that indicated on the nameplate of the machine.

(2) All lines must comply with national standards.

(3) It must be reliably grounded, and the grounding wire must comply with electrical standards.

(4) The voltage fluctuation shall not exceed ± 10% of the rated voltage.
